QSC E18SW 18-Inch Passive Subwoofer

The E18SW is a high-performance direct radiation subwoofer with a single, 800W, 18-inch, aluminum frame woofer. It’s designed to produce crushing low-end for live performance with kick-drum and bass in the PA or for high-level, high-energy dance music. A threaded, M20 pole socket is provided for sub/satellite use with any of the E Series two-way models. For portable applications it includes attachment points for four optional casters. The subwoofer’s 4-ohm impedance means that a single woofer can be optimally powered by a less expensive amplifier.E Series loudspeakers will perform very well with any quality, professional power amplifier – but by taking advantage of the complete QSC entertainment system, more performance and options are available. Today’s powered loudspeakers rely on finely tuned digital signal processing (DSP) to achieve a higher level of performance. When used with QSC GXD or PLD amplifiers or with a QSC TouchMix digital mixer, E Series loudspeakers can also take advantage of advanced DSP. QSC has developed E Series DSP settings for all three platforms. These settings support a variety of applications including live sound reinforcement (with and without subwoofers), stage monitoring, dance music and karaoke.

• High output, professional quality sound with 800 W continuous power
• E Series Entertainment System – Advanced digital signal processing tunings and options using QSC GXD, PLD amplifiers or TouchMix digital mixers.
• Titanium diaphragm for high fidelity and long life
• Rugged tour-grade textured paint
• Foam-lined perforated steel grill
• E18SW includes speaker pole

• Configuration: 1 x 18-inch, subwoofer, non-powered
• Frequency Range (-10 dB): 50Hz to 120Hz
• Coverage Angle: N/A
• Power capacity continuous/peak:800 W / 3200 W
• Sensitivity: 97dB, 1W@1m
• Ouput (peak SPL @ 1 m):132dB
• Driver LF: 457 mm (18-inch) driver with 100 mm (4-inch) voice coil
• Driver HF: N/A
• Nominal Impedance: 4 ohms
• Cross-over: Recommended 80-120Hz LPF
• Input connectors: 2x NL4, 1 barrier strip
• Enclosure: Rectangular, plywood, black texture paint finish. Four side-mounted handles. Rear panels provision for optional casters. Perforated, powder-coated steel grille with foam lining.
• Mounting and suspension: M20 threaded pole-mount socket
• Net weight: 43 kg / 94 lbs
• Shipping weight: 48 kg / 105 lbs
• Dimensions: 590x616x605mm (23.2x24.2x23.8in)
