Elation SATURA SPOT CMY PRO 320w LED Moving Head

Elation Satura Spot CMY PRO 320w LED Moving Head

The new Satura Spot CMY is a high powered LED spot luminaire featuring a 320W LED engine delivering comparable color output to a 575W fixture, 11,700 total lumens output, 14° to 36° motorized zoom, CMY color mixing, 7 dichroic colors, 6 rotating interchangeable and 7 static-stamped gobos, 5 variable dimming curve modes, zoom, focus, and iris, 3-facet rotating prism, Art-NET (DMX over Ethernet) support, 3 and 5 pin DMX, EtherCON (RJ45) in/out, and powerCON connections, an internal EWDMX wireless DMX receiver, (6) button control full color 180° reversible menu display, 500W max power consumption, and a multi-voltage universal auto switching power supply (100-204v).

Features:
  • Comparable color output to a 575W fixture
  • CMY color mixing and CTO color correction
  • Art-NET (DMX over ethernet) support
  • Internal EWDMX wireless DMX receiver
  • Flicker free operation for broadcast tv and film
    • Specifications:
  • Source: 320W LED engine / 50,000 hour average LED life
  • Photometric data: 11,700 total lumens, 8,000K / 27,430 LUX 2,548 FC @8.2’ (2.5m) (14° zoom full on) / 4,735 LUX 440 FC @8.2’ (2.5m) (36° zoom full on)
  • Effects: frost filter, 3-facet rotating prism, iris: 5% - 100%, strobe: 1-18fps, dimming: 0% - 100%, variable dimming curve modes
  • Color: 7 dichroic colors + white (open), CMY color mixing + CTO
  • Gobos: 2 Gobo wheels, 6 interchangeable / rotating / indexing gobos, 7 static-stamped / indexing gobos
  • Controls: 22, 24 or 33 DMX channels
  • RDM (Remote Device Management)
  • 6 button touch control panel
  • Full color 180° reversible LCD menu display
  • 8 / 16-Bit resolution adjustable movement
  • Connections:
    • 3pin and 5pin DMX in/out
    • etherCON (RJ45) in/out (Art-NET)
    • powerCON Power In
  • Size: 20.0" X 16.9" X 28.6" (508mm X 430mm X 727mm) (LxWxH)
  • Weight: 66.1 Lbs./30 kg
  • Electrical and thermal: AC 100-240V - 50/60Hz / -13°F to 113°F (-25°C to 45°C)
  • Max power consumption: 500W
  • Approvals and ratings: CE | IP20
  • Included items: (2) Omega Brackets, (1) 3pin DMX Cable, (1) Safety Cable, (1) powerCON Cable
    • $1,500.00

    Original: $4,999.99

    -70%
    Elation SATURA SPOT CMY PRO 320w LED Moving Head—

    $4,999.99

    $1,500.00

    Product Information

    Shipping & Returns

    Description

    Elation Satura Spot CMY PRO 320w LED Moving Head

    The new Satura Spot CMY is a high powered LED spot luminaire featuring a 320W LED engine delivering comparable color output to a 575W fixture, 11,700 total lumens output, 14° to 36° motorized zoom, CMY color mixing, 7 dichroic colors, 6 rotating interchangeable and 7 static-stamped gobos, 5 variable dimming curve modes, zoom, focus, and iris, 3-facet rotating prism, Art-NET (DMX over Ethernet) support, 3 and 5 pin DMX, EtherCON (RJ45) in/out, and powerCON connections, an internal EWDMX wireless DMX receiver, (6) button control full color 180° reversible menu display, 500W max power consumption, and a multi-voltage universal auto switching power supply (100-204v).

    Features:
  • Comparable color output to a 575W fixture
  • CMY color mixing and CTO color correction
  • Art-NET (DMX over ethernet) support
  • Internal EWDMX wireless DMX receiver
  • Flicker free operation for broadcast tv and film
    • Specifications:
  • Source: 320W LED engine / 50,000 hour average LED life
  • Photometric data: 11,700 total lumens, 8,000K / 27,430 LUX 2,548 FC @8.2’ (2.5m) (14° zoom full on) / 4,735 LUX 440 FC @8.2’ (2.5m) (36° zoom full on)
  • Effects: frost filter, 3-facet rotating prism, iris: 5% - 100%, strobe: 1-18fps, dimming: 0% - 100%, variable dimming curve modes
  • Color: 7 dichroic colors + white (open), CMY color mixing + CTO
  • Gobos: 2 Gobo wheels, 6 interchangeable / rotating / indexing gobos, 7 static-stamped / indexing gobos
  • Controls: 22, 24 or 33 DMX channels
  • RDM (Remote Device Management)
  • 6 button touch control panel
  • Full color 180° reversible LCD menu display
  • 8 / 16-Bit resolution adjustable movement
  • Connections:
    • 3pin and 5pin DMX in/out
    • etherCON (RJ45) in/out (Art-NET)
    • powerCON Power In
  • Size: 20.0" X 16.9" X 28.6" (508mm X 430mm X 727mm) (LxWxH)
  • Weight: 66.1 Lbs./30 kg
  • Electrical and thermal: AC 100-240V - 50/60Hz / -13°F to 113°F (-25°C to 45°C)
  • Max power consumption: 500W
  • Approvals and ratings: CE | IP20
  • Included items: (2) Omega Brackets, (1) 3pin DMX Cable, (1) Safety Cable, (1) powerCON Cable
