Elation ELAR-DRIVER-8 8 Channel Universal DMX LED

The ELAR Driver 8 is an 8-channel universal 24V DMX LED driver with a built-in power supply.

• Universal 24V LED Driver with Built-In Power Supply
• 12 position dipswitch for DMX addressing and function set up
• USITT DMX512 (1990) compatible
• DMX and Stand Alone operation modes
• 0- 100% Stand Alone Fade Time setting
• 0.1S - 30S Stand Alone Chase Speed setting
• 7 built in programs
• All Outputs Individually Controllable by DMX (32 DMX channels)
• DMX Output Operation Modes:
• Pure White (Intensity) (One DMX Channel)
• Color with white saturation (Two DMX Channels)
• RGB (Three DMX Channels)
• RGBW (Four DMX Channels)
• Power Input (selectable) 110- 120VAC (3.2A) / 220- 240VAC (1.6A) 50/60Hz
• Power Failure Memory
• DMX Input: 3-Pin XLR male connector
• DMX Output: 3-Pin XLR female connector
• Dimensions: 286mm x 191mm x 74mm
• Weight: 3kg
• Operation Temperature: -10°C to +50°C
• Storage Temperature: - 20°C to +70°C
