Elation ACL PAR 200 IP 7x 15 Watt RGBW LED Light

The new ACL PAR 200IP™ is a versatile IP65 rated par luminaire featuring (7) individual 15W RGBW 4-in-1 LEDs and the new advanced collimator optic lens, producing a laser-like homogenized 4° color-changing beam from each lens which combined produce a 11° beam angle. Features include full individual pixel control, strobe, and selectable dimming curve effects, DMX, RDM (Remote Device Management) support, IP DMX and power in/out connections, (4) touch control pads, LCD menu display, 110W max power consumption, and a multi-voltage universal auto switching power supply (100-240v).

Features

• Versatile IP65 Rated Par Luminaire
• New Advanced Collimator Lens
• (7) Pixel Control RGBW 4-in1 LEDs
• Laser-Like Homogenized 4° Color Changing Beams
• Strobe and Selectable Dimming Curves
• Flicker Free Operation for Broadcast TV and FILM

Source

• (7) 15W RGBW 4-in-1 LEDs
• 100,000 Hour Average Lamp Life*
• *LED Life may vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.

Photometric Data (Full ON)

• 56,149 LUX 5,216 FC @3.3’ (1m)
• 36,935 LUX 3,431 FC @6.6’ (2m)
• 20,439 LUX 1,899 FC @9.8’ (3m)
• 11,897 LUX 1,105 FC @13.1’ (4m)
• 7,617 LUX 708 FC @16.4’ (5m)

Effects

• Individual Pixel Control
• Strobe and Selectable Dimming Curves

Color

• RGBW

Control / Connections

• (11) DMX Channel Modes:
• (4CH1:04 / 4CH2:04 / 6 / 8 / 10 / 12 / 27 / 28 / 30 / 32 / 35)
• RDM (Remote Device Management)
• 4 Touch Control Pads
• LCD Menu Display
• IP DMX In/Out
• IP Power In/Out

Size / Weight

• Length: 12.3" (313mm)
• Width: 6.9" (174.5mm)
• Vertical Height: 11.8" (300mm)
• Weight: 14.0 lbs. (6.4 kg)

Electrical / Thermal

• AC 100-240V - 50/60Hz
• 110W Max Power Consumption
• Power Linking: 9pcs Max @110V / 21pcs Max @230V
• 5F to 113°F (-15°C to 45°C)

Approvals / Ratings

• CE | IP65

Installation

• Rigging: Clamps (Not Included)
• Working Position: Any (360°)

Included Items

• Male Edison to IP Female Power Cable 6,6 ft. (2m)
• Male 3pin XLR to IP Female DMX Input Cable 3.3 ft (1m)
• Female 3pin XLR to IP Male DMX Output Cable 3.3 ft (1m)
