Chauvet Ovation MIN-E-10CWZ LED Ellipsoidal

Ovation Min-E-10WW is the perfect complement in form and function to the bigger Ovation E-190WW in a handy, almost pocket sized version. Powered by a punchy 10 W warm white LED, this ultra discreet ellipsoidal features a four-blade shutter system to efficiently and cleanly crop light from unwanted areas, and the interchangeable lens tubes slide in and lock down at the desired focus point. Ovation Min-E-10WW is easily dimmed using external LED lighting dimmer packs.

Features:

• Compact LED ellipsoidal shines a hard-edged beam perfect for gobo projection
• Fade the LED by connecting to a dimmable circuit
• Highlight areas by altering the projected beam with framing shutters
• Easily print your own gobos on transparency film or use standard size E glass or metal gobos
• Interchangeable lens tubes available in 19™ and 36™ beam angles

Specifications:

Optical:

• Light Source: 1 LED (WW) 13 W, (1,000 mA), 50,000 hours life expectancy
• Color Temperature (at full): 3050 K
• Beam Angle (w/19™ lens): 12™
• Beam Angle (w/36™ lens): 21™
• Field Angle(w/19™ lens): 19™
• Field Angle(w/36™ lens): 35™
• Illuminance (w/19™ lens): 195 lux @ 5 m
• Illuminance (w/36™ lens): 50 lux @ 5 m

Dynamic Effect:

• Dimmer: Electronic
• Focus: Manual

Construction / Physical:

• Dimensions (fixture only): 8.9 x 4.3 x 9.1 in (225 x 108 x 232 mm)
• Dimensions (w/19™ lens extended): 11.5 x 4.3 x 9.1 in (291 x 108 x 232 mm)
• Weight (fixture only): 3.0 lb (1.4 kg)
• Weight (w/19™ lens): 3.6 lb (1.6 kg)
• Exterior Color: Black
• Gobo Size (Optional): Gobo holder size E: 37.5 mm (outside), 28 mm (image), 1 mm (max. thickness)
• Accessory Holder/Gel Frame Size: 2.75 in(70 mm)

Connections:

• Power Connection: Edison plug to hard-wired
• Power Input: Hard-wired
• Cable Length (power): 5 ft (1.5 m)

Electrical:

• Input Voltage: 120 VAC, 60 Hz or 230 VAC, 50 Hz
• Power and Current: 12 W, 0.091 A @ 120 V, 60 Hz
• Power and Current: 10 W, 0.055 A @ 230 V, 50 Hz

Certifications / Qualifications:

• CE, MET
• IP Rating: IP20, dry location

What's Included:

• Ovation Min-E-10WW
• Gobo holder size E: 37.5 mm (outside), 28 mm (image), 1 mm (max. thickness)
• Gel frame (2.75 in/70 mm accessories)

equaired Accessories:

• 19™ Lens Tube
• 36™ Lens Tube
