Chauvet DMX-RT DMX Playback Recorder

DMX-RT is a rugged and compact DMX recording device with triggerable playback. Copy, backup and transfer show files with a built-in micro SD card slot and included micro SD card. The unit comes with a mounting bracket for convenient mounting options. The digital display is easy to navigate and lets you easily trigger scenes.

• Rugged and compact DMX recording device with triggerable playback
• Normally open (N/O) or normally closed (N/C) triggers allow the use of most common sensors
• Easily navigate and trigger scene using the digital display
• Copy, backup and transfer show files with a built-in micro SD card slot and included micro SD card
• Integrated mounting bracket to quickly install into any location.
• Supplies DC voltage through terminal block to power specific triggers

• DMX connectors: 3-pin XLR
• Input voltage: 12 VDC, 1 A (external power supply: 100-240 VAC, 50/60 Hz)
• Power and current: 1 W, 0.03 A @ 120 V, 60 Hz, 1 W, 0.03 A @ 230 V, 50 Hz
• Approvals: CE
• Programmable scenes: 999
• Trigger type: N/O or N/C
• Terminal block output: 12 VDC, 100 mA
• Memory card: 8GB (included) 32GB (max) Micro SD
• Format: FAT32
• Included: power adapter, warranty card, and quick reference guide
• Dimensions: 3" x 2.9" x 1.7" / 77 mm x 73 mm x 43 mm
• Weight: 0.4 lbs. / 0.2 kg
