Audio Technica ATMX381 8 Ch Pro Auto Smart Mixer

Equipped with optional computer control, the AT-MX381 SmartMixer is the latest addition to Audio-Technica's family of automatic mixers. This microprocessor-controlled automatic mixer is designed to provide automatic mixing functions for installed sound, house of worship, broadcast and conference applications. Engineered for intuitive, easy-to-use operation, the new SmartMixer automatically keeps the number of open microphones to a minimum, bringing background noise and feedback under control and providing increased clarity and audio quality.

Eight balanced inputs allow use with both mic- and line-level signals. Each input provides:

• Phantom power (48V), individually selectable
• Individual gain and volume controls
• Gate attenuation (adjustable)
• Low-cut filter (individually selectable via SmartMixer Software)

• An RS232 data port provides a connection point for a PC with included SmartMixer Software
• Compatible with Crestron and AMX systems
• External control capability enables the SmartMixer to activate other devices: Force-On - allows an external contact closure to force its associated input to turn on, Force-Off - allows an external contact closure to force its associated input to turn off, Control Voltage Out - a voltage appears when the associated input's gate opens or turns "on"
• Selectable NOMA (Number of Open Mics Attenuated) circuitry helps control feedback
• Priority pre-select feature allows priority of each microphone to be independently assigned
• Last Mic On selectable for continuous room ambiance
• Linking capability for 16 units (up to 128 channels)
• A direct output connection is available for each input
• Equipped with two audio outputs (one balanced, one unbalanced) to drive amplification systems or other equipment
• Monitor headphone output with level control
• Basic functions are configured via front panel; detailed settings through SmartMixer Software
• Mounts in a single 19" rack space via integral rack mount
